Machine Design 4 Stroke
Honda Boat engines are famous for saving fuel without oil mixture. Save the environment.
Full Position in the Middle
Very easy to adjust the position of control to make it easier to control the boat / ship. The position of the lever, PTT switch, engine light headlights in front provide driving comfort.
Induction 3: 3
design 3 light and solid carburetor, using 1 carburetor on each cylinder. So that the Honda boat engine is more responsive, smoother responsive.
PGM Combustion System
Microprocessors accurately control combustion time. Starting from being turned on until it is used in all RPMs providing optimal operation.
Automatic Adjustment
In the electric starter, it automatically regulates the mixture of air and fuel. Facilitate the Honda boat engine turned on or heated.
Best Placement
Special rubber spare parts make Honda boat engines have minimal vibration in all speeds.
Positive Lubrication
The crankshaft resembles an automotive engine. Oil pumps keep each engine component longer, not easily damaged.
Early Warning
Honda Boat Engine Gives visual, sound warnings and reduces RPM speeds. Warn operators from overheating, oil shortages and excessive use. Prevents engine damage.
3 cooling holes
providing plenty of water keeps the engine at a safe temperature.
Corrosion protection
layers of coated paint are double closed, waterproof connectors provide protection from rust.
Discharge pit
Can be cleaned using clean water, remove dirt and seawater, out of the engine. Extend the life of the Honda outboard engine.
Easy Maintenance
The position of the filter and the cover in front, making it easy for maintenance, replacement. Cheap spare parts Reduce maintenance and repair costs.
Fuel/Induction System | 3 Carburetor |
---|---|
Full throttle rpm range | 5000 ~ 6000 r/m |
Jenis Bahan Bakar | Bensin / Gasoline |
Shaft Length | Short - 15" |
Ignition System | PGM-IG |
Exhaust | Through Propeller Hub (JET) |
Tenaga | 20 hp / pk |
Displacement | 552 cc |
Engine Type | 4 Cylinder - 4 Tak / Stroke (outboard) |
Alternator Output | 12v-10Amp (120Watt) |
Gear Shift | Forward - Netral - Reverse |
Starting System | Electric |
Propeller Material | Aluminum |
Trim & Tilt Method | Power Trim & Tilt |
Operation Method | Single Remote Control 703 Without Tachometer |
Cooling System | Forced Water |
