is a 2 stroke boat engine that produces 5 horsepower (HP)
16-valve dohc engine with optimal rpm rotation at 4500-5500 r / m provides strong thrust. , very economical fuel consumption is only 2.8 liters / hour with an internal fuel tank with a capacity of 2.8 liters
Yamaha Outboard Engine 5 pk has advantages in maneuverability of 360º degrees
Yamaha 5CMHS is suitable for use
- inflatable boat
- small wooden ship
- mini fiber ship
1 year warranty
| Fuel/Induction System | 1 Carburetor |
|---|---|
| Full throttle rpm range | 4500 ~ 5500 r/m |
| Jenis Bahan Bakar | Bensin / Gasoline |
| Shaft Length | Short - 15" |
| Lubrication | Pre Mixing |
| Spark Plug | B7HS or BR7HS |
| Ignition System | CDI |
| Exhaust | Above Prop |
| Tenaga | 5 hp / pk |
| Displacement | 103 cc |
| Engine Type | 1 Cylinder - 2 Tak / Stroke (outboard) |
| Max Prop Shaft Output | 11 kw (15ps) @ 5000 r/m |
| Compression Ratio | 6.5 |
| Fuel Consumption | 2.8 litres per hour |
| Alternator Output | 12-3.3Amp (40W) |
| Gear Shift | Forward - Netral - Reverse |
| Estimated Speed | 10~15 mph or 8.68 knot -17.36 knot |
| Starting System | Manual Choke |
| Propeller Pitch Size | 8" |
| Propeller Material | Aluminum |
| Gear Ratio | 2.08 (27:13) |
| Trim & Tilt Method | Manual Tilt |
| Operation Method | Tiller handle |
| Cooling System | Forced Water |
| Fuel Tank | Built in Fuel Tank - 2.8L |
| Dry Weight | 21 kg |
